Education Hydraulic Apparatus

The learning system works with hydraulic transparent components. With the complete system, the basics and advanced topics related to hydraulics are conveyed.

Educational Objectives

• Basics of Hydraulics
• Hydraulic components with special functions
• Basic hydraulic circuits

Function

Hydraulic elements from are operated with red-coloured hydraulic oil. The white base plate further heightens the contrast. A maximum operational pressure of 10 bar (1 MPa) facilitates safe experimentation. The transparent connecting hoses and introduced air bubbles allow learners to fully follow the flow paths: from pressure connection of the pump through to the tank connection. The learning system conveys the fundamentals of hydraulic systems on three levels. The electro-hydraulics are designed for a safe 24 V direct current.
